GraviTrac

GraviTrac®

Series

Weighing Robot

Sirius GraviTrac® Weighing Robot with OMNI technology delivers fast and accurate weighing of labware ranging from minitubes to large containers i.e. 500mL Nalgene bottles. This robot also supports barcode-based or position-based labware sorting / cherry-picking.

GraviTrac for a single container type.

GraviTrac Capping/Uncapping.

GraviTrac for multiple container types with auto finger swap.

  The Auto-Sampler to Your Analytical Balances

  Fast (~10 secs roundtrip/piece)

  Capping/UnCapping Options

  Improves Data Quality with Process Consistency and Electronic Auditable History

  Reliable Walkaway Operation

  Best Use of Valuable Headcount

Key Functions

  0.1mg or 0.01mg Accuracy Weighing
   (Tare/Gross/Replicate Weights)

●  High-Speed Barcode Scanning with
    Rotating Gripper and Wingman®
    Scanner

●  2D Matrix Barcode Reading
    for MiniTubes

●  Barcode-Based or Position-Based
     Sorting

●  Capping/UnCapping
●  Email Notifications (Start/Stop/Etc.)
●  Seamless LIMS Integration
●  Optional ToolSwap® Finger Changer
    to Handle Multiple Labware Types

Specifications

Dimensions(inch): 48 W x 27 D x 41 H
Space Requirements(inch): 84 W x 36 D x 48 H
Weight (lb): ~100
Power: 120 – 240 VAC, 10A, 50/60 Hz
Air 4 bar (60 psi) / Vacuum: 380 mm Hg (15″ Hg)
Operating Temperature: 14-35C
Humidity: 5-85%
